CC Racing
USA "MONSTER 29.5cc" Full Mod
Race Zenoah Engine
If you
are looking for the ultimate power plant for your boat with all the bells and
whistles then look no further, the "MONSTER" is
the engine is that you have been looking for. This engine comes with all the
best hot ups in one package.
This is the engine your friends
don't want you to buy. We start off with a brand new reliable
genuine Zenoah
G290PUM marine engine with E/Z
Starter then we add CC Racing
exclusive Ceramic Crank Bearings, Zenoah +1.0mm
stroker crank, Low Drag Seals, Light weight Flywheel, CC Racing CNC lightened
Piston, Copper Base gasket, CC Racing CNC Ported and hand finished cylinder,
CC Racing Billet Carb Isolator, CC Racing Modified Wt257 carb with Billet
needle clamp and all high quality Stainless bolts.
Here is what's done:
 | New engine disassembled and all parts
Inspected and cleaned |
| Machine work is done to piston and cylinder
|
| Piston is modified lightened and reshaped
|
| Transfer ports are modified for maximum
airflow without sacrificing airspeed |
| Exhaust Port modified and reshaped for
optimum scavenging and supercharging |
| Intake Port modified and reshaped for optimum
flow and pulse signal |
| Finishing hand port work to piston and
cylinder |
| Port timings are set for intake and exhaust
ports |
| Low drag seals installed |
| All bolts replaced with high grade
Stainless steel bolts |
| Base gasket replaced with copper base
gasket |
| Walbro WT-257 Carburetor is bored and
modified and Needle clamp installed |
| Water Jacket replaced with Laser Etched CC
Racing Jacket |
| Champion spark
plug is replaced with a high quality NGK plug |
| Engine is then professionally assembled
|
| CC Racing Billet Isolater block is used
|
| Stock crank is replaced with
a genuine Zenoah +1.0 mm stroker
crank |
| CC Racing design ceramic crankshaft
bearings are installed |
